Vibration Pen, Portable Vibration Meter, Velocity Tester, Motor Bearings Gears Detector VM-7000

Name: Vibration Pen Portable Vibration Meter Velocity Tester Motor Bearings Gears Detector VM7000
Brand: RAYTECH
Price: 1 USD

China Vibration Pen, Portable Vibration Meter, Velocity Tester, Motor Bearings Gears Detector VM-7000 factory

Brand Name : RAYTECH

Model Number : VM-7001

Certification : ISO CE

Place of Origin : China

MOQ : 1unit

Payment Terms : Western Union, T/T, L/C

Supply Ability : 5000units per month

Delivery Time : 5days

Packaging Details : Standard Export Carton

Product Name : Vibration Pen, Portable Vibration Meter, Velocity Tester, Motor Bearings Gears Detector VM-7000

Temperature range : 0 - 50°C

Parameters : Velocity

Testing range : Velocity:0.01mm/s-199.9mm/s(RMS)

Frequency range : Velocity:10Hz~1kHz

Display : 31/2 digits LCD

Contact Now

Vibration Pen, Portable Vibration Meter, Velocity Tester, Motor Bearings

Gears Detector VM-7000

Features:
• Used for fast failure detecting of motor, electric fan, pump, air compressor, machine tools and so on.
• Compact size, small weight, easy handling
• Prompt testing of vibration on the workshop machines
• For quick checking of unbalance misalignment, bearings and gears
• Guard against mechanical malfunction
• Holding tested value for 40 seconds
• Automatic switch off after 40 seconds

• VM-7000 is used for testing of velocity

Parameters	Velocity
Testing range	Velocity:0.01mm/s-199.9mm/s(RMS)
Frequency range	Velocity:10Hz~1kHz
Accuracy	±5%
Display	31/2 digits LCD
Power supply	Two button batteries(LR44 or SR44)
Battery capacity	Approx 4.5 hours working continuously
Operating Temperature	0℃~40℃
Humidity	＜85%
Dimension	150mm2218mm
Dimension Weight	55g(including batteries)

Standard delivery
• Main unit
• Battery
• Protection pocket
• Certificate
• Instruction manual
• Warranty card

TAG: Digital Vibration Testing Machine Vibration Meter Vibration Pen
